Home > products > OPZV OPZS > ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System

ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System

Product Details

Place of Origin: China

Brand Name: Yangtze

Certification: CE/TUV/ISO/ROHS/MSDS

Model Number: OPZV-490

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: negotiable

Packaging Details: Pallet+Carton box

Delivery Time: 7-20 days

Payment Terms: L/C, T/T, Western Union,Credit Card

Supply Ability: 5000 units/week

Get Best Price
Highlight:

V 490Ah OPZV Battery

,

Wind Solar Energy OPZV Tubular Battery

,

Tubular OPZV OPZS Battery

Container Material:
ABS
Recombination Efficiency:
≥99%
Float Voltage:
2.25-2.35V/cell
Operating Temperature Range:
–40℃ To +60℃
Capacity Range:
200Ah-3000Ah
Self Discharge:
≤3%/month
Design Life:
30 Years
Impedance:
≤0.5mΩ
Container Material:
ABS
Recombination Efficiency:
≥99%
Float Voltage:
2.25-2.35V/cell
Operating Temperature Range:
–40℃ To +60℃
Capacity Range:
200Ah-3000Ah
Self Discharge:
≤3%/month
Design Life:
30 Years
Impedance:
≤0.5mΩ
ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System



Product Description:

OPZV OPZS tubular batteries are designed to provide the highest recombination efficiency and design life. With a recombination efficiency of ≥99%, a design life of 30 years, and a container material of ABS, these batteries are built to last. The operating temperature range is –40℃ To +60℃, and the float voltage of the battery is 2.25-2.35V/cell. OPZV OPZS tubular batteries are the perfect choice for reliable, long-term energy storage.

ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 0

1. Functional Parameter 5. Environment Temperature
Nominal Voltage 2V Discharge Temperature -40~60
Nominal Capacity @C10 to 1.8V/cell 490Ah Charge Temperature -15~50
Designed Floating Life 20 (68° F) 20years Storage Temperature -15~40
2. Rated Capacity at 20 (68° F) 6. Inner Resistance & Max . Discharge Current
5 hour rate (85.3A, 1.75V/cell) 426.5Ah Fully Charged battery at 20 (68° F) 0.75mΩ
3 hour rate (126A, 1.75V/cell) 378Ah Max. Discharge Current 2000A (5s)
1 hour rate (279A, 1.60V/cell) 279Ah Short Circuit Current 2600A
3. Capacity affected by Temperature (10 hour rate) 7. Self-discharge at 20 (68° F)
40 (104° F) 102% Capacity after 3 month storage 94%
25 (77° F) 100% Capacity after 6 month storage 88%
0 (32° F) 90% Capacity after 9 month storage 82%
-15 (5° F) 70% Capacity after 12 month storage 76%
4. Dimension and Weight 8. Constant voltage charging at 20 (68° F)
Length 166mm Cyclic use 2.35~2.40V
Width 206mm Maximum charging current 100A
Height 471mm Temperature compensation -5mV/
Total Height 506mm Float use 2.25~2.29V
Reference Weight 37.3kg Temperature compensation -3mV/

ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 1
ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 2ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 3ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 4ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 5

ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 6ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 7ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 8ABS 2V 490Ah Tubular OPZV Battery For Wind Solar Energy System 9

Features:

  • Product Name: OPZV OPZS
  • Float Voltage: 2.25-2.35V/cell
  • Container Material: ABS
  • Design Life: 30 Years
  • Capacity Range: 200Ah-3000Ah
  • Recombination Efficiency: ≥99%
