Product Description:
AGM Gel Battery is an advanced gel battery with absorptive glass mat technology. It is designed to provide superior performance and long-term reliable energy storage. The sealed storage battery has a voltage of 12V and an operating temperature range of -20℃ to 60℃. It also features a low self-discharge rate of ≤3%/month and a cycle life of up to 1500 times. This powerful and reliable Absorbed Glass Mat Battery has a wide range of applications, making it an excellent choice for any energy storage needs.
Features:
- Product Name: AGM Gel Battery
- Sealed Type: Sealed Storage Battery
- Maintenance Type: Free
- Cycle Life: 1500 Times
- Voltage: 12V
- Self-discharge: ≤3%/Month
- Technology: Absorptive Glass Mat Battery, Absorbed Glass Mat Battery, Absorptive Glass Mat Battery
| 1. Functional Parameter |
5. Environment Temperature |
| Nominal Voltage |
12V |
Discharge Temperature |
-15~50℃ |
| Nominal Capacity (20 hour rate) |
9Ah |
Charge Temperature |
0~40℃ |
| Number of Cells |
6cells |
Storage Temperature |
-15~40℃ |
| 2. Rated Capacity at 25℃ (77° F) |
6. Inner Resistance & Max . Discharge Current |
| 20 hour rate (0.05C, 10.8V) |
9Ah |
Fully Charged battery at 25℃ (77° F) |
24mΩ |
| 5 hour rate (0.165C, 10.8V) |
7.6Ah |
Max. Discharge Current |
135A (5s) |
| 1 hour rate (0.55C, 10.5V) |
5.35Ah |
Short Circuit Current |
450A |
| 3. Capacity affected by Temperature (10 hour rate) |
7. Self-discharge at 25℃ (77° F) |
| 40℃ (104° F) |
103% |
Capacity after 3 month storage |
91% |
| 25℃ (77° F) |
100% |
Capacity after 6 month storage |
82% |
| 0℃ (32° F) |
85% |
Capacity after 9 month storage |
73% |
| -15℃ (5° F) |
65% |
Capacity after 12 month storage |
64% |
| 4. Dimension and Weight |
8. Constant voltage charging at 25℃ (77° F) |
| Length |
151mm |
Cyclic use |
14.4~14.9V |
| Width |
65mm |
Maximum charging current |
2.7A |
| Height |
110mm |
Temperature compensation |
-30mV/℃ |
| Total Height |
115mm |
Float use |
13.6~13.8V |
| Reference Weight |
2.8kg |
Temperature compensation |
-20mV/℃ |
Technical Parameters:
| Parameter |
Value |
| Battery Case |
ABS Plastic Battery Box |
| Operating Temperature |
-20℃~60℃ |
| Sealed Type |
Sealed Storage Battery |
| Voltage |
12V |
| Cycle Life |
1500 Times |
| Terminal |
M8/M10 |
| Maintenance Type |
Free |
| Self-discharge |
≤3%/Month |
Applications:
The Yangtze 6-GFM(G)-65 Absorbed Glass Mat (AGM) Gel Battery is the perfect choice for reliable and safe energy storage in a wide range of applications. This high-performance battery features a unique sealed construction with ABS plastic battery box, high-quality components, and a low self-discharge rate of ≤3%/Month. Thanks to its operating temperature range of -20℃~60℃, this AGM Gel Battery is ideal for both indoor and outdoor use. It is also designed for a cycle life of 1500 times and is certified with CE/TUV/ISO/ROHS/MSDS. With a minimum order quantity of 1 unit and negotiable price, this product is available in pallet and carton box packaging and has a delivery time of 7-20 days. Payment terms include L/C, T/T, Western Union, and Credit Card. We also guarantee a supply capacity of 10000 units/week.
Packing and Shipping:
Packaging and Shipping AGM Gel Battery
AGM Gel Battery products are shipped in boxes that are designed to provide protection during shipping and storage. The boxes are made of durable corrugated cardboard and are labeled clearly with the product name and product number.
Each product is securely packed in its own box. The box is filled with foam or bubble wrap to prevent the product from shifting during shipping. The box is sealed with tape for extra security.
The products are shipped via standard shipping services such as UPS, FedEx, or USPS to ensure a safe and timely delivery. We also offer expedited shipping services for customers who need their order quickly.
FAQ:
| Q: |
A: |
| What is the brand name of AGM Gel Battery? |
The brand name of AGM Gel Battery is Yangtze. |
| What is the model number of AGM Gel Battery? |
The model number of AGM Gel Battery is 6-GFM(G)-65. |
| Where is AGM Gel Battery made? |
AGM Gel Battery is made in China. |
| What certifications does AGM Gel Battery have? |
AGM Gel Battery has CE/TUV/ISO/ROHS/MSDS certification. |
| How many AGM Gel Batteries can I buy? |
The minimum order quantity for AGM Gel Battery is 1 unit. |
