Product Details
Place of Origin: China
Brand Name: Yangtze
Certification: CE/TUV/ISO/ROHS/MSDS
Model Number: 6-GFM-12
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: Pallet+Carton box
Delivery Time: 7-20 days
Payment Terms: L/C, T/T, Western Union,Credit Card
Supply Ability: 10000 units/week
Voltage: |
12V |
Battery Case: |
ABS Plastic Battery Box |
Terminal: |
M8/M10 |
Self-discharge: |
≤3%/Month |
Maintenance Type: |
Free |
Sealed Type: |
Sealed Storage Battery |
Cycle Life: |
1500 Times |
Operating Temperature: |
-20℃~60℃ |
Voltage: |
12V |
Battery Case: |
ABS Plastic Battery Box |
Terminal: |
M8/M10 |
Self-discharge: |
≤3%/Month |
Maintenance Type: |
Free |
Sealed Type: |
Sealed Storage Battery |
Cycle Life: |
1500 Times |
Operating Temperature: |
-20℃~60℃ |
AGM Gel Battery is a type of Advanced Glass Battery, also known as Absorptive Glass Mat Battery. It is an advanced type of rechargeable battery designed for reliable and stable performance. Its superior design and construction makes it an ideal choice for applications requiring a long service life and maintenance-free operation. AGM Gel Battery is characterized by its excellent cycle life, reaching up to 1500 times, and its wide operating temperature range of -20℃~60℃. It also features an ABS Plastic Battery Box to ensure reliable protection against harsh environment and mechanical shocks, and its terminals can be either M8 or M10, providing a voltage of 12V. This makes it a perfect power solution for various applications.
1. Functional Parameter | 5. Environment Temperature | ||
Nominal Voltage | 12V | Discharge Temperature | -15~50℃ |
Nominal Capacity (20 hour rate) | 12Ah | Charge Temperature | 0~40℃ |
Number of Cells | 6cells | Storage Temperature | -15~40℃ |
2. Rated Capacity at 25℃ (77° F) | 6. Inner Resistance & Max . Discharge Current | ||
20 hour rate (0.05C, 10.8V) | 12Ah | Fully Charged battery at 25℃ (77° F) | 20mΩ |
5 hour rate (0.165C, 10.8V) | 10Ah | Max. Discharge Current | 180A (5s) |
1 hour rate (0.55C, 10.5V) | 7.1Ah | Short Circuit Current | 600A |
3. Capacity affected by Temperature (10 hour rate) | 7. Self-discharge at 25℃ (77° F) | ||
40℃ (104° F) | 103% | Capacity after 3 month storage | 91% |
25℃ (77° F) | 100% | Capacity after 6 month storage | 82% |
0℃ (32° F) | 85% | Capacity after 9 month storage | 73% |
-15℃ (5° F) | 65% | Capacity after 12 month storage | 64% |
4. Dimension and Weight | 8. Constant voltage charging at 25℃ (77° F) | ||
Length | 151mm | Cyclic use | 14.4~14.9V |
Width | 98mm | Maximum charging current | 3.6A |
Height | 94mm | Temperature compensation | -30mV/℃ |
Total Height | 100mm | Float use | 13.6~13.8V |
Reference Weight | 3.8kg | Temperature compensation | -20mV/℃ |
AGM Gel Battery, produced by Yangtze, is a high-quality and reliable advanced gel mat battery. It has a model number of 6-GFM(G)-65 and is certified by CE/TUV/ISO/ROHS/MSDS. It has a minimum order quantity of 1 unit and its price is negotiable. It is packaged in pallet plus carton box and has an estimated delivery time of 7-20 days. Payment terms include L/C, T/T, Western Union, and credit card. It has a supply ability of 10000 units per week and operating temperature of -20℃~60℃. Its terminal type is M8/M10 and its battery case is ABS plastic battery box. It has an output voltage of 12V and maintenance type of free. This AGM Gel Battery, with its superior Absorbed Glass Mat Battery technology and Absorptive Glass Battery technology, is an ideal choice for various applications.
AGM Gel Battery Packaging and Shipping
AGM gel batteries are generally packaged in containers that are designed for safe transport and storage. The packaging materials used include corrugated cardboard, plastic wrap, bubble wrap, and other protective materials. The containers are designed to protect the batteries from being damaged, scratched, or broken during transport or storage. For shipping, AGM gel batteries are often shipped in special boxes or containers that are designed to protect the batteries from shock, vibration, and other environmental factors.
It is important to check the packaging and shipping instructions for the AGM gel batteries before shipping them, as improper packaging or shipping can lead to damage or malfunction. Additionally, it is important to make sure that the batteries are stored in a dry, cool place and away from any direct sunlight or other sources of heat. This will help to keep the batteries in good working condition and ensure that they are working properly when they arrive at their destination.
