Product Description:
Advanced Gel Battery, also known as Absorbed Glass Mat Battery or Advanced Gel Mat Battery, is the latest technology in the AGM Gel Battery. With its excellent self-discharge rate of ≤3% per month, it has a cycle life of 1000 times, and operates under a wide temperature range from -20℃ to 60℃, with a float voltage of 13.5V to 13.8V. This product is designed to provide a reliable power backup for any application, from long-term backup to standby power. With its advanced technology, AGM Gel Battery is the perfect choice for any of your power needs.
| 1. Functional Parameter |
5. Environment Temperature |
| Nominal Voltage |
12V |
Discharge Temperature |
-15~50℃ |
| Nominal Capacity (10 hour rate) |
200Ah |
Charge Temperature |
0~40℃ |
| Number of Cells |
6cells |
Storage Temperature |
-15~40℃ |
| 2. Rated Capacity at 25℃ (77° F) |
6. Inner Resistance & Max . Discharge Current |
| 10 hour rate (0.1C, 10.8V) |
200Ah |
Fully Charged battery at 25℃ (77° F) |
3mΩ |
| 3 hour rate (0.25C, 10.8V) |
153.3Ah |
Max. Discharge Current |
3000A (5s) |
| 1 hour rate (0.55C, 10.5V) |
110.4Ah |
Short Circuit Current |
10000A |
| 3. Capacity affected by Temperature (10 hour rate) |
7. Self-discharge at 25℃ (77° F) |
| 40℃ (104° F) |
103% |
Capacity after 3 month storage |
91% |
| 25℃ (77° F) |
100% |
Capacity after 6 month storage |
82% |
| 0℃ (32° F) |
85% |
Capacity after 9 month storage |
73% |
| -15℃ (5° F) |
65% |
Capacity after 12 month storage |
64% |
| 4. Dimension and Weight |
8. Constant voltage charging at 25℃ (77° F) |
| Length |
522mm |
Cyclic use |
14.4~14.9V |
| Width |
240mm |
Maximum charging current |
50A |
| Height |
219mm |
Temperature compensation |
-30mV/℃ |
| Total Height |
223mm |
Float use |
13.6~13.8V |
| Reference Weight |
59.5kg |
Temperature compensation |
-20mV/℃ |
Features:
- Product Name: AGM Gel Battery
- Type: Absorbed Glass Mat Battery (AGM), Absorptive Glass Mat Battery (AGM) or Advanced Gel Mat Battery (AGM)
- Self-discharge: ≤3%/Month
- Operating Temperature: -20℃~60℃
- Charge Voltage: 14.4V~14.7V
- Terminal: M8/M10
Applications:
Yangtze AGM Gel Battery is the ideal choice for applications which require high performance, long life and superior charging capability. It offers a wide range of benefits, including an advanced Absorbed Glass Mat (AGM) technology for improved power delivery and superior cycle life, a superior charge voltage of 14.4V~14.7V, a float voltage of 13.5V~13.8V, a self-discharge rate of ≤3%/Month, a discharge cut-off voltage of 10.5V~11.0V, and M8/M10 terminal type. It is certified with CE/TUV, and it is made in China.
For anyone looking to power their equipment with a reliable and robust energy solution, Yangtze AGM Gel Battery is the perfect choice. It is highly durable and provides superior performance, allowing you to get the most out of your equipment. Its advanced AGM technology ensures reliable power delivery and long-lasting battery life, while its superior charge voltage and discharge cut-off voltage guarantee maximum efficiency and safety. It also features an extremely low self-discharge rate and a convenient M8/M10 terminal type, making it the ideal choice for a wide range of applications.
Customization:
AGM Gel Battery
- Brand Name: Yangtze
- Place of Origin: China
- Certification: CE/TUV
- Voltage: 12V
- Terminal: M8/M10
- Cycle Life: 1000 Times
- Self-discharge: ≤3%/Month
- Discharge Cut-off Voltage: 10.5V~11.0V
AGM Gel Battery is an advanced Gel Battery, also known as an Absorptive Glass Mat Battery and Absorptive Glass Battery, which is highly reliable and features excellent performance. It has been certified by CE/TUV and is suitable for 12V voltage. The terminal is M8/M10, and it has a cycle life of 1000 times and a self-discharge rate of ≤3%/month. The discharge cut-off voltage is between 10.5V~11.0V.
Packing and Shipping:
Packaging and Shipping for AGM Gel Battery
- All AGM Gel Batteries will be packed with protective foam to ensure they remain safe during the shipping process.
- All shipments will be securely sealed to protect against water or other elements.
- Shipments will be sent via ground or air depending on the customer's requirements.
- All packages will be labeled with the customer's name, address, and contact information.
- Shipping fees will be determined by the weight and size of the package.
