Innovative Design Transparent BIPV Glass Modules Solar Panel With Cutting-Edge Features

Product Details

Place of Origin: China

Brand Name: Yangtze

Certification: CE/TUV/ISO/ROHS/INMETRO

Model Number: YS700M-BI

Payment & Shipping Terms

Minimum Order Quantity: 30 pieces

Price: negotiable

Packaging Details: Pallet+Carton Box

Delivery Time: 7-20 days

Payment Terms: L/C, T/T, Western Union,Credit Card

Supply Ability: 20000 pieces/Week

Get Best Price
Highlight:

Transparent BIPV Panels

,

Frameless BIPV Solar Panels

,

BIPV Glass Modules Solar Panel

Frame:
Anodized Aluminium Alloy/Frameless
Junction Box:
IP68 Rated
Solar Cell:
Half Cell 10BB
Glass:
High Transmission Low Iron Tempered Glass
Backing Color:
White Or Black Or Transparent
OEM Order:
Acceptable
Class:
Grade A
Rated Power:
700W
Frame:
Anodized Aluminium Alloy/Frameless
Junction Box:
IP68 Rated
Solar Cell:
Half Cell 10BB
Glass:
High Transmission Low Iron Tempered Glass
Backing Color:
White Or Black Or Transparent
OEM Order:
Acceptable
Class:
Grade A
Rated Power:
700W
Innovative Design Transparent BIPV Glass Modules Solar Panel With Cutting-Edge Features

700W Bipv Solar Panel Transparent Film Cladding Glass Frameless For Window

Product Description:

BIPV Solar Panels are ideal for residential and commercial applications due to their high efficiency of between 18% and 22%, their use of mono-crystalline cells, and their ability to output between 200W and 700W of power. The panels are equipped with MC4 type connectors, and they operate at a current range of 6A to 10A. BIPV Solar Panels provide a reliable and efficient form of clean energy, making them the perfect choice for anyone looking for an environmentally-friendly way to power their home or business.



Features:

  • Product Name: BIPV Solar Panels
  • Operating Voltage: 36V-48V
  • Temperature Range: -40°C To 85°C
  • Type: BIPV Solar Panels
  • Cell Type: Mono-crystalline
  • Warranty: 25 Years



Applications:

Yangtze BIPV Solar Panels from China offer high-efficiency power output ranging from 200W-700W with an efficiency of 18%-22%, operating current of 6A-10A, and a 25-year warranty and 25-30 year lifespan. Our BIPV Solar Panels are perfect for residential and commercial rooftops, carports, and other projects, providing a great renewable energy source. Yangtze BIPV Solar Panels are reliable and have a long life span, making them an ideal choice for any solar-powered project.



Customization:

Customized BIPV Solar Panels

Our custom-made BIPV Solar Panels are manufactured with the highest quality standards using premium materials and components. We use top-of-the-line brand Yangtze from China with a lifespan of 25-30 years and a power output of 200W-700W. The operating voltage ranges from 36V-48V, and the material used is aluminum alloy. Moreover, our panels come with a 25-year warranty.



Support and Services:

BIPV Solar Panels Technical Support and Service

We provide technical support and service for BIPV Solar Panels. Our team of experienced professionals are available to answer any questions and provide professional advice and assistance. We can help you with installation, maintenance, troubleshooting, and product selection.

We are committed to providing the highest quality service and support. If you ever have any questions or concerns, please contact us right away. We will do our best to provide you with a satisfactory solution.

Thank you for choosing BIPV Solar Panels. We look forward to assisting you in any way we can.



Packing and Shipping:

BIPV Solar Panels are packaged and shipped using the following method:

  • The panels are securely packaged in a sturdy cardboard box.
  • The box is then sealed with adhesive tape.
  • The package is labeled with the customer's details.
  • The package is then shipped via a reputable courier.

Innovative Design Transparent BIPV Glass Modules Solar Panel With Cutting-Edge Features 0

Model Type
YS500M-BI
YS600M-BI
YS700M-BI
Rated Maximum Power at STC
500W
600W
700W
Maximum Power Voltage (Vmp)
48.40V
42.10V
39.58V
Maximum Power Current (Imp)
10.33A
14.25A
17.69A
Open Circuit Voltage ( Voc)
58.08V
49.99V
46.75V
Short Circuit Current (Isc)
10.54A
14.97A
18.92A
Module Efficiency
22.81%
23.27%
23.30%
Working Conditions&Working Conditions
Glass Thickness
2mm 4mm 6mm 8mm 10mm 12mm
Transmittance
10% 20% 30% 40% 50% 60% 70% 80%
Operating Temperature
-40°c~+85°c
Maximum System Voltage
DC 1000V(IEC) / 1500V(IEC)
Maximum Series Fuse
25A
Power Tolerance
0~+5W
Temperature Coefficient of Pmax
-0.35%/°c
Temperature Coefficient of Voc
-0.29%/°c
Temperature Coefficient of Isc
+0.048%/°c
STC(Standard Testing Conditions): lrradiance 1000W/m2 , Cell Temperature 25 'C, Spectra at AMl.5
NOCT (Nominal Operating Cell Temperature): lrradiance 800W/m2 , Ambient Temperature 20 'C, Spectra at AMl.5, Wind at l m/S
