Home > products > Mono Facial Solar Panel > 120Cells 166mm Mono Facial Solar Panel 390W Anti PID IP68 Waterproof

120Cells 166mm Mono Facial Solar Panel 390W Anti PID IP68 Waterproof

Product Details

Place of Origin: China

Brand Name: Yangtze

Certification: CE/TUV/ISO/ROHS/INMETRO

Model Number: YS390M-120

Payment & Shipping Terms

Minimum Order Quantity: 30 pieces

Price: negotiable

Packaging Details: Pallet+Carton Box

Delivery Time: 7-20 days

Payment Terms: L/C, T/T, Western Union,Credit Card

Supply Ability: 20000 pieces/Week

Get Best Price
Highlight:

166mm Mono Facial Solar Panel

,

Anti PID Mono Facial Solar Panel

,

Waterproof 390w mono solar panel

Frame:
Anodized Aluminium Alloy
Junction Box:
IP68 Rated
Solar Cell:
Half Cell 9BB
Glass:
3.2mm High Transmission Low Iron Tempered Glass
Backing Color:
White Or Black Or Transparent
OEM Order:
Acceptable
Class:
Grade A
Rated Power:
390W
Dimension:
1755*1038*35mm
Efficiency:
21.75%
Frame:
Anodized Aluminium Alloy
Junction Box:
IP68 Rated
Solar Cell:
Half Cell 9BB
Glass:
3.2mm High Transmission Low Iron Tempered Glass
Backing Color:
White Or Black Or Transparent
OEM Order:
Acceptable
Class:
Grade A
Rated Power:
390W
Dimension:
1755*1038*35mm
Efficiency:
21.75%
120Cells 166mm Mono Facial Solar Panel 390W Anti PID IP68 Waterproof

390W Mono-facial Solar Panel 120Cells 166mm Excellent Anti-PID Performance


Product Description:

Introducing the Mono-facial Solar Panel – a single-sided sun panel that provides the highest efficiency and reliability in its class. This solar panel is equipped with an MC4 Connector for easy installation and an IP68 Junction Box for protection against dust and water ingress. The anodized aluminum alloy frame provides a robust structure and ensures durability in all weather conditions. With its 25-year warranty, the Mono-facial Solar Panel is the ideal choice for residential and commercial applications.



Features:

  • Product Name: Mono-facial Solar Panel
  • Frame Material: Anodized Aluminum Alloy
  • Cell Type: Mono-crystalline
  • Warranty: 25 Years
  • Connector Type: MC4
  • Temperature Range: -40℃~+85℃
  • Features: Single-sided Sun Paneling, Single-sided Sun Panel, Single-sided Sun Panel

Applications:

The Mono-facial Solar Panel from Yangtze in China is the perfect solution for a variety of applications. The Mono-facial Sun Panel is designed with a Minimum Order Quantity of 1 and a Delivery Time of 10-20 days. The Junction Box is rated IP68, and the Temperature Range is from -40℃~+85℃. The frame is made of Anodized Aluminum Alloy and the Cell Type is Mono-crystalline. This Mono-facial Solar Panel is durable and reliable, and can be used in a variety of applications ranging from residential and commercial to industrial and agricultural.



Customization:

Customized Mono-facial Solar Panel from Yangtze
  • Brand Name: Yangtze
  • Place of Origin: China
  • Minimum Order Quantity: 1
  • Delivery Time: 10-20 days
  • Product Name: Mono-facial Solar Panel
  • Junction Box: IP68
  • Connector Type: MC4
  • Frame Material: Anodized Aluminum Alloy
  • Warranty: 25 Years

We offer customized Mono-facial Solar Panel from Yangtze with single-sided sun panel, IP68 junction box, MC4 connector type and anodized aluminum alloy frame material. Enjoy your 25 years warranty and our fast delivery in 10-20 days.



Packing and Shipping:

Packaging and Shipping

Mono-facial Solar Panel will be packaged carefully in a box with foam padding for protection during shipment. All packages are shipped using a reliable courier service.

Shipping fees include handling and packing fees as well as postage costs. Handling fees are fixed, whereas transport fees vary according to total weight of the shipment. We advise you to group your items in one order. We cannot group two distinct orders placed separately, and shipping fees will apply to each of them.

120Cells 166mm Mono Facial Solar Panel 390W Anti PID IP68 Waterproof 0



Model Type
YS380M-120
YS385M-120
YS390M-120
YS395M-120
YS400M-120
Rated Maximum Power at STC
380W
385W
390W
395W
400W
Maximum Power Voltage (Vmp)
34.65V
34.69V
34.73V
34.77V
34.82V
Maximum Power Current (Imp)
10.97A
11.09A
11.23A
11.39A
11.49A
Open Circuit Voltage ( Voc)
41.01V
41.16V
41.31V
41.46V
41.60V
Short Circuit Current (Isc)
11.53A
11.63A
11.73A
11.83A
11.93A
Module Efficiency
20.92%
21.19%
21.47%
21.75%
21.98%
Working Conditions&Working Conditions
Operating Temperature
-40°c~+85°c
Maximum System Voltage
DC 1000V(IEC) / 1500V(IEC)
Maximum Series Fuse
25A
Power Tolerance
0~+5W
Temperature Coefficient of Pmax
-0.35%/°c
Temperature Coefficient of Voc
-0.29%/°c
Temperature Coefficient of Isc
+0.048%/°c
STC(Standard Testing Conditions): lrradiance 1000W/m2 , Cell Temperature 25 'C, Spectra at AMl.5
NOCT (Nominal Operating Cell Temperature): lrradiance 800W/m2 , Ambient Temperature 20 'C, Spectra at AMl.5, Wind at l m/S
